≤ 12
≤ 12
A
A
Collector temperature sensor in the flow
Low flow operation — single sided connection
≤ 8
A
A
Collector temperature sensor in the flow
Low flow operation — connection on alternate sides
≤ 10
A
A
Collector temperature sensor in the flow
13.4 Installation examples Vitosol 200-TM, type SPEA
Take ventilation into consideration when designing the collector
arrays (see chapter "Ventilation" on page 132).
Note
Max. 20 m
2
absorber area can be connected in series to form a sin-
gle array.
Vertical installation on pitched roofs, installation on collector supports or horizontal installation
Single row installation; connection from the left or right
A
20 m²
A
Collector temperature sensor
Information regarding design and operation
(cont.)
VITOSOL
VIESMANN
123
5822 440 GB
13
