Viessmann Vitocell 360-M - Tested quality

Type SV2F SH2F SV2D
Installation position (see following diagram)
A, C, D B, C, D, E A, C, D
E
C
B
A
D
90
51
90
2200
2380
1056
KV
KR
Type SV2F/SV2D
KR Collector return (inlet)
KV Collector flow (outlet)
90
51
90
2380
876
1056
KV
KR
Type SH2F
KR Collector return (inlet)
KV Collector flow (outlet)
3.3 Tested quality
These collectors meet the requirements of the "Blue Angel" eco-
label to RAL UZ 73.
Tested in accordance with Solar KEYMARK to EN 12975 or ISO
9806.
CE designation according to current EC Directives
Vitosol 200-FM, type SV2F/SH2F and Vitosol 200-F, type SV2D
(cont.)
