Viessmann Vitocell 360-M - Temperature Controller as Temperature Limiter (Maximum Limit)

130
72
95
100-200
Specification
Connection 3-core lead with a cross-section of
1.5 mm
2
IP rating IP 41 to EN 60529
Switching point 120 (110, 100, 95) °C
Switching differential max. 11 K
Breaking capacity 6(1.5 ) A, 250 V~
Switching function with rising temperature from 2 to 3
3 2
1
DIN reg. no. DIN STB 1169
Temperature controller as temperature limiter (maximum limit)
Part no. Z001 887
With stainless steel sensor well R½ x 200 mm.
With setting scale in the casing.
130
72
95
100-200
Specification
Connection 3-core lead with a cross-section
of 1.5 mm
2
Setting range 30 to 80 °C
Switching differential max. 11 K
Breaking capacity 6(1.5) A 250 V~
Switching function with rising temperature from 2 to
3
3 2
1
DIN reg. no. DIN TR 1168
Temperature controller
Part no. 7151 989
Suitable for:
■ Vitocell 100-B
■ Vitocell 100-V
■ Vitocell 340-M
■ Vitocell 360-M
■ With a thermostatic system
■ With selector on the outside of the casing
■ Without sensor well
■ With top-hat rail to be fitted to the DHW cylinder or the wall
1400
95
72
130
Specification
Connection 3-core lead with a cross-section of
1.5 mm
2
IP rating IP 41 to EN 60529
Setting range 30 to 60 °C, adjustable up to 110 °C
Switching differential Max. 11 K
Breaking capacity 6 (1.5) A 250 V~
Switching function with rising temperature from 2 to 3
3 2
1
DIN registration number DIN TR 1168
Solar control units
(cont.)
