Viessmann Vitocell 360-M - Collector Supports with Fixed Angle of Inclination

b
z
a
2200
A
B
25°
30°
35°
40°
45°
50°
For calculating collector row clearance z, see page 108.
A
Support slab A
B
Support slab B
Vitosol 300-TM, type SP3C
Combination a mm b mm
1.51 m
2
/1.51 m
2
505/505 595
1.51 m
2
/3.03 m
2
505/1010 850
3.03 m
2
/3.03 m
2
1010/1010 1100
Collector supports with fixed angle of inclination
15
75
c
A
B
C
A
A
Mounting feet
B
Adjustable support
C
Collector support
Ø 11
6x
285
166
144
263
80
40
2186
2440
2461
Angle of inclination 30° 45° 60°
c in mm 2413 2200 1838
Design information regarding flat roof installation
(cont.)
VITOSOL
VIESMANN
115
5822 440 GB
