Viessmann Vitocell 360-M - Vitocell 100-V, type CVW

7.3 Vitocell 100-V, type CVW
For DHW heating in conjunction with heat pumps up to 16 kW and
solar collectors; also suitable for boilers and district heating systems
Suitable for the following systems:
■ DHW temperature up to 95 °C
■ Heating water flow temperature up to 110 °C
■ Solar flow temperature up to 140 °C
■ Operating pressure on the heating water side up to 10 bar
(1.0 MPa)
■ Operating pressure on the solar side up to 10 bar (1.0 MPa)
■ Operating pressure on the DHW side up to 10 bar (1.0 MPa)
Specification
Type CVW
Cylinder capacity l 390
DIN registration no. 9W173-13MC/E
Continuous output for DHW heating from 10 to 45 °C and a heating
water flow temperature of … at the heating water flow rate stated below
90 °C kW 109
l/h 2678
80 °C kW 87
l/h 2138
70 °C kW 77
l/h 1892
60 °C kW 48
l/h 1179
50 °C kW 26
l/h 639
Continuous output for DHW heating from 10 to 60°C and a heating
water flow temperature of … at the heating water flow rate stated below
90 °C kW 98
l/h 1686
80 °C kW 78
l/h 1342
70 °C kW 54
l/h 929
Heating water flow rate for the stated continuous outputs
m
3
/h
3.0
Draw-off rate l/min 15
Drawable water volume without reheating
– Cylinder content heated to 45 °C
Water at t = 45 °C (constant)
l 280
– Cylinder content heated to 55 °C
Water at t = 55 °C (constant)
l 280
Heat-up time if connected to a heat pump with 16 kW rated heating output and a heat-
ing water flow temperature of 55 or 65 °C
– For DHW heating from 10 to 45 °C min 60
– For DHW heating from 10 to 55 °C min 77
Max. connectable heat pump output at 65 °C heating water flow and 55 °C DHW
temperature and the specified heating water flow rate
kW 16
Max. aperture area that can be connected to the solar heat exchanger set (acces-
sories)
– Vitosol-T
m
2
6
– Vitosol-F
m
2
11.5
Performance factor N
L
in conjunction with a heat pump
Cylinder storage temperature 45 °C 2.4
50 °C 3.0
Standby heat loss q
ST
at 45 K temperature differential to EN 12897:2006 kWh/24 h
1.80
Dimensions
Length (7)
– With thermal insulation mm 859
– Excl. thermal insulation mm 650
Total width
– With thermal insulation mm 923
– Excl. thermal insulation mm 881
Height
– With thermal insulation mm 1624
– Excl. thermal insulation mm 1522
Height when tilted
– Excl. thermal insulation mm 1550
Entire weight incl. thermal insulation kg 190
Total weight in operation incl. immersion heater kg 582
Heating water capacity l 27
Heating surface
m
2
4.1
DHW cylinders
(cont.)
