Viessmann Vitocell 360-M User Manual

Type SV1F SH1F SV1B SH1B
Installation position (see following diagram)
A, C, D B, C, D,
E
A, C, D B, C, D, E
E
C
B
A
D
90
38
72
2200
2380
1056
KV
KR
Type SV1F/SV1B
KR Collector return (inlet)
KV Collector flow (outlet)
90
38
72
2380
876
1056
KV
KR
Type SH1F/SH1B
KR Collector return (inlet)
KV Collector flow (outlet)
2.3 Tested quality
These collectors meet the requirements of the "Blue Angel" eco-
label to RAL UZ 73.
Tested in accordance with Solar KEYMARK to EN 12975 or ISO
9806.
Vitosol 100-FM, type SV1F/SH1F and Vitosol 100-F, type SV1B/SH1B
(cont.)
12
VIESMANN
VITOSOL
2
5822 440 GB
