7.1 Vitocell 100-U, type CVUB/CVUC-A
For DHW heating in conjunction with boilers and solar collectors Suitable for the following systems:
■ DHW temperature up to 95 °C
■ Heating water flow temperature up to 160 °C
■ Solar flow temperature up to 110 °C
■ Operating pressure on the heating water side up to 10 bar
(1.0 MPa)
■ Operating pressure on the solar side up to 10 bar (1.0 MPa)
■ Operating pressure on the DHW side up to 10 bar (1.0 MPa)
Specification
Type CVUB CVUC-A
Cylinder capacity l 300 300
DIN registration no. 0266/07-13MC/E
Continuous output, upper indirect coil
For DHW heating from 10 to 45 °C and a heating water flow temperature
of … at the heating water flow rate stated below
90 °C
kW 31
l/h 761
80 °C
kW 26
l/h 638
70 °C
kW 20
l/h 491
60 °C
kW 15
l/h 368
50 °C
kW 11
l/h 270
Continuous output, upper indirect coil
For DHW heating from 10 to 60 °C and a heating water flow temperature
of … at the heating water flow rate stated below
90 °C
kW 23
l/h 395
80 °C
kW 20
l/h 344
70 °C
kW 15
l/h 258
Heating water flow rate for the stated continuous outputs
m
3
/h
3.0
Draw-off rate l/min 15
Drawable water volume
Without reheating
Cylinder content heated to 60 °C
Water at t = 60 °C (constant)
l 110
Standby heat loss Q
ST
at 45 K temperature differential to EN 12897:2006 kWh/24 h 1.52 1.15
Standby capacity V
aux
l 127
Solar capacity V
sol
l 173
Dimensions (incl. thermal insulation)
Length a (7)
mm 660
Total width b mm 840
Height c mm 1735
Height when tilted mm 1830
Weight incl. thermal insulation kg 179
Total weight in operation kg 481
Heating water capacity
– Upper indirect coil l 6
– Lower indirect coil l 10
Heating surface
– Upper indirect coil
m
2
0.9
– Lower indirect coil
m
2
1.5
Connections (male thread)
Heating water flow and return R 1
Cold water, DHW R 1
DHW circulation R 1
Energy efficiency class B A
Information regarding continuous output of the upper indirect
coil
When engineering systems with the specified or calculated continu-
ous output, select a matching circulation pump. The stated continu-
ous output is only achieved when the rated boiler heating output ≥
continuous output.
Note
The cylinder is also available as Vitocell 100-W, type CVUB in white.
The Vitocell 100-W, type CVUC-A is only available in white.
