Rated voltage 230 V~
Rated frequency 50 Hz
Rated current 6 A
Power consumption 6 W; 0.9 W in standby mode
Protection class II
IP rating IP 20 to EN 60529; ensure through de-
sign/installation
Function Type 1B to EN 60730-1
Permissible ambient temperature
– Operation 0 to +40 °C when used in living space
or boiler room (standard ambient condi-
tions)
– Storage and transport −20 to +65 °C
Rated relay output breaking capacity
– Semi-conductor relay 1
to 6
0.8 A
– Relay 7 4(2) A, 230 V~
– Total Max. 6 A
Delivered condition
■ Vitosolic 200, type SD4
■ Collector temperature sensor
■ 2 temperature sensors
Tested quality
CE designation according to current EC Directives
Solar control units
(cont.)
28
VIESMANN
VITOSOL
6
5822 440 GB
