Vitosol-FM/-F flat-plate collectors
Vertical and horizontal installation
B
A
C
D
A
Collector
B
Rafter flange
C
Mounting rail
D
Mounting plate
Vitosol 300-TM vacuum tube collectors, type SP3C
Vertical installation
A
C
D
B
A
Collector
B
Rafter flange
C
Mounting rail
D
Tube retainer
Horizontal installation
A
B
C
D
A
Collector
B
Rafter flange
C
Mounting rail
D
Tube retainer
Design information regarding installation on pitched roofs — above roof installation
(cont.)
106
VIESMANN
VITOSOL
10
5822 440 GB
