F
Rafter
G
Counter batten
Vitosol-FM/-F flat-plate collectors
Vertical and horizontal installation
D
B
A
C
A
Collector
B
Rafter hook
C
Mounting rail
D
Mounting plate
Vitosol 300-TM vacuum tube collectors, type SP3C
Vertical installation
A
C
D
B
A
Collector
B
Rafter hooks
C
Mounting rail
D
Tube retainer
Design information regarding installation on pitched roofs — above roof installation
(cont.)
VITOSOL
VIESMANN
103
5822 440 GB
