7.8 Vitocell 300-V, type EVIA-A
For DHW heating in conjunction with boilers and district heating
systems; optionally with an electric heater (accessories).
Suitable for the following systems:
■ DHW temperature up to 95 °C
■ Heating water flow temperature up to 160 °C
■ Operating pressure on the heating water side up to 10 bar
(1 MPa)
■ Operating pressure on the DHW side up to 10 bar (1 MPa)
Type EVIA-A EVIA-A EVIA-A EVIA-A
Cylinder capacity l 160 200 300 500
DIN registration number Applied for
Continuous output
for DHW heating from 10 to 45 °C and a heating water flow
temperature of … at the heating water flow rate stated below
90 °C kW 39 39 51 69
l/h 952 952 1247 1694
80 °C kW 32 32 42 58
l/h 793 793 1039 1414
70 °C kW 26 26 34 46
l/h 630 630 827 1128
60 °C kW 19 19 25 34
l/h 461 461 607 830
50 °C kW 11 11 15 20
l/h 270 270 358 493
Continuous output
for DHW heating from 10 to 60 °C and a heating water flow
temperature of … at the heating water flow rate stated below
90 °C kW 33 33 43 59
l/h 564 564 740 1011
80 °C kW 26 26 34 46
l/h 444 444 584 799
70 °C kW 18 18 24 33
l/h 313 313 413 568
Heating water flow rate for the stated continuous outputs
m
3
/h
3.0 3.0 3.0 3.0
Standby heat loss kWh/24
h
0.90 0.91 1.06 1.37
Dimensions
Length (Ø) a
– Incl. thermal insulation mm 581 581 667 1022
– Excl. thermal insulation mm – – – 715
Width b
– Incl. thermal insulation mm 605 605 744 1084
– Excl. thermal insulation mm – – – 954
Height c
– Incl. thermal insulation mm 1189 1409 1734 1852
– Excl. thermal insulation mm – – – 1667
Height when tilted
– Incl. thermal insulation mm 1260 1460 1825 –
– Excl. thermal insulation mm – – – 1690
Entire weight incl. thermal insulation kg 60 70 105 110
Heating water capacity l 7.4 7.4 11.0 12.9
Heating surface
m
2
1.0 1.0 1.5 1.7
Connections (male thread)
Heating water flow and return R 1 1 1 1
Cold water, DHW R ¾ ¾ 1 1¼
DHW circulation R ¾ ¾ 1 1
Energy efficiency class A A A A
Information regarding continuous output
When designing systems with the specified or calculated continuous
output, select a matching circulation pump. The stated continuous
output is achieved only if the rated boiler heating output is ≥ the con-
tinuous output.
Note
Up to 300 l cylinder capacity also available as Vitocell 300-W in
"white".
