Viessmann Vitocell 360-M - Page 57

300 l capacity
SPR2
a
b
KW/E
HV/SPR1
BÖ
WW
Z
HR
HVs/SPR2
HRs
c
77
327
Ø 100
876
996
1116
1356
1607
362
SPR1
BÖ Inspection and cleaning aperture
E Drain
HR Heating water return
HR
s
Heating water return, solar thermal system
HV Heating water flow
HV
s
Heating water flow, solar thermal system
KW Cold water
SPR1 Sensor well for cylinder temperature sensor of cylinder tem-
perature controller (internal diameter 7 mm)
SPR2 Sensor well for cylinder temperature sensor/thermometer
sensor (internal diameter 17 mm)
WW DHW
Z DHW circulation
500 l capacity
b
a
SPR
Ø 100
508
HRs
HV
c
KW/E
WW
BÖ
126
Z
HR
HVs/SPR2
SPR1
494
823
948
1073
1252
1625
BÖ Inspection and cleaning aperture
E Drain
HR Heating water return
HR
s
Heating water return, solar thermal system
HV Heating water flow
HV
s
Heating water flow, solar thermal system
KW Cold water
SPR1 Cylinder temperature controller cylinder temperature sensor
(clamping system for fixing immersion temperature sensors
to the cylinder jacket)
SPR2 Temperature sensors/thermometer sensors (clamping sys-
tem for securing immersion temperature sensors to the cylin-
der jacket)
WW DHW
Z DHW circulation
DHW cylinders
(cont.)
VITOSOL
VIESMANN
57
5822 440 GB
