SPECIFICATIONS23
TimingGearCover
T2023649
W2032454
Step1:Positionthecoverinplacewithbolts1and2andinstallalignmenttool.
Step2:Tightentheboltsinthenumericalordershown...........24±4Nm(18±3ft-lb)
Note:Applysealantina2mm(0.079inch)thickbead,maximum20minutesbefore
mounting,andcarefullytightenthecontactsurfacesshownintheenlargedparts
oftheillustration.
