SPECIFICATIONS25

Cover,CrankshaftSseal

W2032696

Step1.Positionthecoverwithbolts1and2andtightentocontact

Step2:Tightentheboltsinnumericalorder1–8asshown......24±4Nm(18±3ft-lb)

Note:Applysealantina2mm(0.079inch)thickbeadasillustratedandtighten

boltsinnumericalorder.
