28SPECIFICATIONS

CylinderHead

T2022734

Step1......................................................................................100±5Nm(74±4ft-lb)

Step2(angletightening)........................................................................120±5degrees

Step3(angletightening)..........................................................................90±5degrees

Note:Thecylinderheadmustbemountedaccordingtoinstructions,seeCylinder

Head,Replacement.
