Mobile Generator John Deere Engines With ECU
wc_tx000698gb.fm 61
6.3 Engine Electrical Components
See Graphic: wc_gr003343
Ref. Component Ref. Component
1 Main circuit breaker 9 Starter relay
2 Engine Control Module (ECM) 10 Oil pressure sensor
3 Alternator 11 Engine Control Unit (ECU)
4 Slave preheat relay 12 Crank position sensor
5 Manifold air temperature sensor 13 Fuel pump assembly
6 Manifold heater 14 Coolant temperature sensor
7 Starter motor 15 Fuel temperature sensor
8 Starter motor solenoid 16 Fuel pump control solenoid
