Disassembly/Assembly Mobile Generator
90 wc_tx000575gb.fm
9.8 Removing the AVR
Prerequisites
Machine shut down
Procedure
Follow the procedure below to remove the Automatic Voltage
Regulator (AVR).
9.8.1 Remove the screws that secure the large access panel (a) and open
the large access panel.
9.8.2 Make note of the wires connected to the AVR (b).
9.8.3 Disconnect the wires.
9.8.4 Remove the screws that secure the AVR and remove the AVR from
the machine.
The procedure to remove the AVR is now complete.
