Disassembly/Assembly Mobile Generator
108 wc_tx000575gb.fm
9.16 Replacing the Voltage Selector Switch (VSS)
See Graphic: wc_gr003284
Electric shock hazard. Turn off the generator before replacing the
Voltage Selector Switch (VSS).
Removal:
9.16.1 Remove the air filter and the cover of the VSS box (a).
9.16.2 Label and disconnect all the wires attached to the VSS.
9.16.3 Remove the switch handle (b) from the VSS.
9.16.4 Remove the screws (c) that secure the front face of the VSS.
9.16.5 Remove the screws that secure the mounting bracket (d) to the VSS
box and remove the VSS and mounting bracket from the VSS box.
9.16.6 Remove the mounting bracket from the VSS (e).
Installation:
9.16.7 Attach the mounting bracket (d) to the VSS (e).
9.16.8 Slide the VSS into the VSS box and secure the face plate (c) with the
screws.
9.16.9 Attach the switch handle (b).
9.16.10 Secure the mounting bracket to the VSS box.
9.16.11 Connect the wiring to the VSS.
9.16.12 Reinstall the cover (a) of the VSS box and the air filter.
WARNING
