Description of the Machine
4.4 Information Label Meanings
26
Operator’s Manual | LTV 4L/6L | 5100065071 | 02/2023 | [en-US]
Notification of National Association of Trailer Manufacturers (NATM) compli-
ance
Lifting point
Light cover
Fork lift pocket
Tie-down point
Manual winch
To raise tower
1. Lift pins and extend outriggers.
2. Raise tower with winch.
3. Loosen mast rotation knob to aim tower. Tighten knob when tower is
aimed.
To lower tower
1. Turn off breakers and engine.
2. Loosen mast rotation knob and rotate tower forward. Tighten knob
when tower is facing forward.
3. Lower tower with winch.
4. Lift pins and retract outriggers.
