Technical Data
Generator 12.2
97
[en-US] | 02/2023 | 5100065071 | LTV 4L/6L | Operator’s Manual
12.2 Generator
LTV4L 240W LED LTV4L 300W LED LTV6L MH LTV6L LED
Frequency 60 Hz 60 Hz 60 Hz 60 Hz
Output 4.1 kW 4.1 kW 6 kW 6 kW
Voltage 120V 120V 120V 120V
Phase 1 1 1 1
Amps 34.2A 34.2A 50A 50A
Excitation Type Capacitor / brushless Capacitor / brushless Capacitor / brushless Capacitor / brushless
Power Factor 1 1 1 1
Voltage Regulation—
No Load to Full Load
0.1 0,1 0.1 0.1
Voltage Regulation—
Steady State
+/- 6.0% +/- 6,0% +/- 6.0% +/- 6.0%
Operating Speed 1800 rpm 1800 rpm 1800 rpm 1800 rpm
12.3 Machine
LTV4L 240W LED LTV4L 300W LED LTV6L MH LTV6L LED
Lamp LED LED Metal Halide LED
Frequency 60 Hz 60 Hz 60 Hz 60 Hz
Lamp Wattage 4 X 240W 4 X 300W 4 X 1100W 4 X 300W
Dimensions 2.56 x 1.47 x 2.51 m
(101 x 58 x 99 in.)
2.56 x 1.47 x 2.51 m
(101 x 58 x 99 in.)
2.56 x 1.47 x 2.51 m
(101 x 58 x 99 in.)
2.56 x 1.47 x 2.51 m
(101 x 58 x 99 in.)
Operating Weight 730 kg (1610 lb) 748 kg (1650 lb) 803 kg (1770 lb) 803 kg (1770 lb)
Height—Mast Extended 7 m (23 ft) 7 m (23 ft) 7 m (23 ft) 7 m (23 ft)
Output 4.1 kW 4.1 kW 6 kW 6 kW
Voltage 120V 120V 120V 120V
Amps 34.2A 34.2A 50A 50A
Power Factor 1 1 1 1
NEMA Beam Spread Type 4 Type 4 Type 6 Type 4
Lighting Coverage @ 5
fc
403 m² (4342 ft²) 518 m² (5582 ft²) 857 m² (9230 ft²) 518 m² (5582 ft²)
Sound Level 68.8 dB(A) 68.8 dB(A) 67.9 dB(A) 67.9 dB(A)
AC Outlet Receptacle 1-125V, 20A Duplex
GFCI
1-125V, 20A Duplex
GFCI
1-125V, 20A Duplex
GFCI
1-125V, 20A Duplex
GFCI
12

Wacker Neuson LTV 4L Specifications

General

Brand	Wacker Neuson
Model	LTV 4L
Category	Work Light
Language	English
