Commissioning
6.14 Positioning the Machine
50
Operator’s Manual | LTV 4L/6L | 5100065071 | 02/2023 | [en-US]
Connecting the wires
Connect the light fixture wires to the coiled cord wires to wires from the four
connectors on the sides of the junction box using Panduit wire crimper
CT-100 according to the following table.
Position Light Fixture Wire Coiled Cord Wire
L1 Black Red
White Orange
Green —
L2 Black Black
White Brown
Green —
L3 Black Yellow
White White
Green —
L4 Black Blue
White Purple
Green —
1. Install and connect the four green wires from the light fixtures, the
green wire from the coiled cord, and the green/yellow ground wire
(found in hardware bag 5) into the large connector.
2. Crimp the wires and the wire joint terminal (found in hardware bag 5)
together using the Panduit wire crimper CT-1500.
3. Attach the loose end of the green/yellow ground wire to the ground
screw(8) in the junction box.
4. Use two wrenches to completely tighten the large connector.
5. Replace the cover plate on the junction box.
6.14 Positioning the Machine
DANGER
Asphyxiation hazard
Exhaust gas from the machine contains carbon monoxide, a deadly poison
you cannot see or smell. Exposure to carbon monoxide can kill you in min-
utes.
► Position the machine so that exhaust will not enter any nearby struc-
tures.
