Operation

Control Panels and Receptacles—Deep Sea 7.6

[en-US] | 02/2023 | 5100065071 | LTV 4L/6L | Operator’s Manual

7.6 Control Panels and Receptacles—Deep Sea

2 3 4 6

7 8 9 10 11

12 13

1 5

Fig.34: Control panel and receptacles

Ref. Description Ref. Description

1 Menu navigation buttons (up/

down)

2 Controller display

3 Main circuit breaker 4 GFCI circuit breaker

5 Lights circuit breaker 6 Tower winch rotary switch (op-

tional)

7 Stop/reset button 8 Auto start button

9 Start button 10 Hour meter

11 Control panel light 12 20A GFCI receptacle

13 30A receptacle (optional) — —
