Wacker Neuson RD24 - Checking Coolant Level

Maintenance
Drive unit/diesel engine
142
BA RD24_RD27 en 04
1
3
4
4
4 4 1
2
2
Check the radiator
Check the cooling fins of the radiator for fouling.
a
Cooling fins not soiled: The machine is ready for operation.
a
Cooling fins contaminated: Clean the cooling fins thoroughly and
without delay.
Cleaning the radiator
Switch off the diesel engine and remove the ignition key.
Allow the machine to cool down to less than 30 °C (86 °F).
Open the bonnet [2].
Clean the radiator [1] carefully from all sides using a pressure washer.
Close the bonnet [2].
NOTE
If necessary, remove the panel [3] from the bonnet [2] by
undoing four screw connections [4].
4.03.09 Checking coolant level
& Lubricant only admissible if containing this marking ("Technical data",
page 165 sqq.).
12
