Operation
Driving with dynamic compaction system
BA RD24_RD27 en 04
95
switched off when at low or high speed.
NOTE
Always preset manual mode when restarting the machine.
Preselect the roller drum
The dynamic compression of the roller drums can be performed both in
combination and single for every roller drum.
Press switch [2].
a
The pilot LEDs [3] of the preselected roller drums light up in green.
To select or unselect the roller drums either individually or in combination,
repeatedly press the switch [2].
Activating/deactivating the compaction system
Activate the drum
Press the switch [4].
a
The vibration/oscillation symbol [5] lights up.
a
The selected drum is ready for operation with vibration/oscillation.
NOTE
The activation option depends on the configuration of your
machine:
■
Without additional designation: Vibration at the front
and/or rear.
■
O: Oscillation at the rear.
■
C: Rear tyres (no dynamic compaction).
Setting drum in vibration
Requirement: Diesel engine is running.
Press switch at drive lever [6].
a
In accordance with the settings, the compaction system works
immediately (manual) or when driving starts (automatic).
Switch off vibrations
Press switch at drive lever [6] again.
3.19.02 Jump operation (RMV)
Display for versions with add-on equipment
NOTE
No even compaction measurement can be realised during jump
operation. In this case, the compaction parameters (HM value)
are not reliable any longer.
The vibrating drum must not be lifted from the ground (jump operation)
during compaction in earth moving work.
■
A slow flashing of the display indicates that the drum is immediately
before jump operation.
■
A fast flashing of the display indicates that the drum is in jump
operation.
Increasing or descreasing driving speed.
Increase or reduce the motor speed.
