Description
Control stand
BA RD24_RD27 en 04
45
2.02.02 Operating station controls
2
2
3
1
5
4
[1] Steering column [2] Driving lever
[3] Switch for all-wheel lock [4] Switch for water sprinkling system
[5] Switch for additive sprinkling system
2.02.03 Steering column
2
4 5 6 7
1 3
[1] Steering wheel [2] Control panel
[3] EMERGENCY STOP [4] Preselection engine speed
[5] Electrical system/engine start switch [6] Switch seat heating (option)
[7] KAG sprinkler switch (option)
