Wacker Neuson RD24 User Manual

Tables
Technical data
BA RD24_RD27 en 04
179
5.01.03 RD24-100C
Designation Value Unit
Dimensions and weights
Unladen weight without ROPS roll-over bar 2134 kg
Operating weight with ROPS roll-over bar 2385 kg
Front/rear axle load 1210/1175 kg
Axle load per tyre 293.75 kg
Working width/max. working width 1000/1050 mm
Inside/outside turning radius 2470/3470 mm
Diesel engine
Manufacturer Kubota
Type D1503
Number of cylinders 3
Power (ISO 14396)/nominal speed 22.9/2700 kW/rpm
EU/USA exhaust emissions standard III A/–
Carbon dioxide emissions (CO
2
)
(1)
797 g/kWh
Transmission
Working gear speed 0–12.0/(0–7.5) km/h/(mph)
Hill climbing ability, vibration on/off 30/40 %
Max. longitudinal gradient allowed 20 °
Max. transverse gradient allowed 20 °
Tyres
Tyre size 205/60-R15
Number of tyres at rear 4 items
Tyre weight 30 kg
Air pressure 0.3/(3.0)/[44] MPa/(bar)/[psi]
Wheel nut tightening torque 170 Nm
Vibration
Vibration front
Frequency/speed, max. engine speed 67/4020 Hz/rpm
Frequency/speed, max. engine speed 2/3 52/3120 Hz/rpm
Max. amplitude 0.45 mm
Steering
Steering lock to both sides 32 °
Pendulum compensation upwards and downwards 8 °
Track offset
Track offset to the right 50 mm
Filling quantities
Fuel 42.00 l
Engine oil (for oil change) 7.00 l
