Description
Control stand
BA RD24_RD27 en 04
47
Version with auxiliary equipment
1
2
3
5
4 6 1 7 8
12 10
9 11
[1] Warning and pilot lights [2] Driving light, turn signals, signal horn
[3] Work light [4] Rotating beacon
[5] Parking brake [6] Hazard warning light
[7] Dynamic compaction system [8] Water sprinkling system control
[9] Tank content fill level [10] Info display for system info/diagnostic codes
[11] Compaction display [12] without function
2.02.05 Drive lever
2
1
3
[1] Driving lever [2] Dynamic compaction system/chip spreader ON/
OFF switch
[3] KAG lifting/lowering switch
