Auxiliary equipment
Seven-pole electrical outlet for trailers
202
BA RD24_RD27 en 04
6.04 Seven-pole electrical outlet for trailers
6.04.01 Overview
When driving on public roads, the trailer must also be equipped with
functional lighting. A socket is provided for the electrical connection
between machine and trailer.
1 2
[1] Socket 7 pole [2] Towing coupling
6.04.02 Fuses
WARNING
Fire in the machine electrical system!
Serious injuries or death or material damage as a result of fire caused
by using fuses not meeting specifications.
■
Only use fuses specified by the manufacturer (not fuses with a
higher amperage).
■
Do not bridge fuses.
CAUTION
Electrical voltage!
Risk of injury due to electric shock.
■
Before starting maintenance work, set the battery isolating
switch to off in order to de-energize the electrical system. As
an alternative, disconnect the earthing/grounding strip from the
battery.
■
Wear personal protective equipment.
■
When working on the electrical system, be sure to only use
suitable and approved tools.
