Tables
Diagnostic Code
BA RD24_RD27 en 04
191
5.04 Diagnostic Code
NOTE
The original operator control panel of the series has been adapted and enlarged in part in order
to improve operator control and functional checks for different pieces of add-on equipment,
In some cases, this may lead to changes in operator control sequences and procedures. They
are described in the instructions.
Please check which operator control panel is installed in your machine.
5.04.01 Standard design
Code No Component Possible cause
00 No malfunction
01 Reverse light control Short-circuit
02 Reverse light control Open lines
03 Left working spotlights left control Short-circuit
04 Left working spotlights left control Defective
05 Right working spotlights right control Short-circuit
06 Right working spotlights right control Defective
07 Drum edge lighting control Short-circuit
08 Drum edge lighting control Defective
09 Pump additive irrigation control Short-circuit
10 Pump additive irrigation control Defective
11 Left driving light control Short-circuit
12 Left driving light control Defective
13 Right driving light control Short-circuit
14 Right driving light control Defective
15 Solenoid valve KAG up and solenoid valve
KAG down control
Open lines, defective
16 Lift KAG solenoid valve activation Short-circuit
17 Solenoid valve KAG down control Short-circuit
18 Solenoid valve vibration rear or solenoid
valve amplitude
Open lines, defective
19 Solenoid valve vibration rear Short-circuit
20 Large solenoid valve amplitude Short-circuit
21 Emergency stop solenoid valve or front vi-
bration solenoid valve
Open lines, defective
22 Solenoid valve EMERGENCY STOP Short-circuit
23 Solenoid valve vibration front Short-circuit
24 Parking brake Short-circuit, line break
25 Control rotating light Open lines
26 Control rotating light Short-circuit
27 Control Pump water irrigation Open lines
28 Control Pump water irrigation Short-circuit
