Auxiliary equipment
Bypass filter for hydraulic oil
226
BA RD24_RD27 en 04
Switch off diesel engine and remove ignition key.
Allow machine to cool down to a temperature under 30 °C (86 °F).
Unscrew and remove the filter casing [1] together with the seal ring
[3].
Replace the gasket ring [3].
Pull off the filter insert [2] and replace it by a new one.
Inspect the inside of the filter casing [1] for dirt. Clean if necessary.
Screw on and tighten the filter casing [1].
Start the diesel engine; Check the filter for leaks.
Check oil level of the hydraulic system with the diesel engine at a
standstill. Top up the stipulated hydraulic oil if necessary.
