ELECTRICAL CIRCUIT – OPERATOR
5. ENCODERS
Each motor, which is housed in each column, has an encoder. The encoder is used to track the motor’s
posion and to ensure accurate torque monitoring.
The primary column’s encoder typically terminates into the Primary Operator terminals White wire/Blue
ferrule - #9, Orange wire/White ferrule- #10, Blue wire/White ferrule - #11, White wire/Orange ferrule-
#12 and the encoder ground into #13.
The secondary column’s encoder typically terminates into the Secondary Operator terminals White wire/
Blue ferrule - #34, Orange wire/White ferrule- #35, Blue wire/White ferrule - #36, White wire/Orange
ferrule - #37 and the encoder ground into #38.
Terminaon points for ALTERNATIVE cable type, if supplied in lieu of the above:
The primary column’s encoder typically terminates into the Primary Operator terminals Black wire/
White ferrule - #9, Red wire/Orange ferrule - #10, White wire/White ferrule - #11, Black wire/Orange
ferrule - #12 and the encoder ground into #13.
The secondary column’s encoder typically terminates into the Secondary Operator terminals Black wire/
White ferrule - #34, Red wire/Orange ferrule- #35, White wire/White ferrule - #36, Black wire/Orange
ferrule - #37 and the encoder ground into #38.
