TROUBLESHOOTING
Troubleshoong
Details on How to Troubleshoot the SpeedGate
The gate pathway and surrounding
areas should be cleared of any and all
obstrucons before operaon is resumed.
Operator Fault Codes
Faults can be acknowledged provided they are not reset automacally. Some errors cannot just be
acknowledged and cleared; they must be dealt with before resuming gate operaon.
Common Faults
Error Descripon Cause/Soluon
F�030
Motor Stall Usually caused by an obstrucon blocking the gate
movement or the motor brake (24VDC) not geng power,
thus not releasing, and stalling the motor. Inspect for:
‒ Mechanical wear and tear.
‒ Gate or motor blocked by obstrucon.
‒ Too lile speed.
‒ Absolute or incremental encoder not ghtened
suciently in its mounng.
‒ Wrong posioning system selected (P.205).
‒ Failure of relay to brake or failure of brake.
F�211
External Stop circuit #1 In the operator terminals 1 and 2 are for the external stop
circuit #1. These terminals are normally jumped. Ensure
that the jumper is seated properly in both terminals.
This error would be tripped by the brake disconnect switch
on FEIG Gen II (i.e., SpeedGate models introduced in 2021).
