Wallace Perimeter Security SPEEDGATE - Installation and Commissioning Checklist

8
wallaceperimetersecurity.comPhone: 866.300.1110
INSTALLATION AND COMMISSIONING CHECKLIST
Installaon and Commissioning Checklist
Complete Step Descripon Manual
Secon
Reference(s)
1. Pallet shipped to site from Wallace Perimeter Security (WPS). page 44
2. Install gate onto concrete anchors; ensure all components level.
(Swing toward property side recommended.)
page 45
3. Mount operator cabinet. page 54
4. Complete electrical connecons: page 57
4.1 Conduit between primary and secondary columns: page 59
page 61
page 63
page 68
4.1.1 Low voltage wiring to post terminaon box, excluding the
encoder and motor cables.
as above
4.2 Between the SpeedGate and the operator cabinet: as above
4.2.1 Motor cables to be kept a minimum of 18 inches from the
secondary (control) wiring.
as above
4.2.2 Mul-conductor low voltage cable. as above
4.2.3 Encoder cables. as above
4.3 Between the vehicle loops and the operator cabinet: as above
4.3.1 Vehicle detector loops leads. as above
4.4 From operator cabinet to building: as above
4.4.1 Power supply (2 hots, 1 ground @ 208-240V single phase). as above
4.4.2 Control wiring. as above; also
page 86 to
page 99
5. Commissioning, following mechanical and electrical porons of
the SpeedGate installaon:
