SPEEDGATE Installation and Maintenance Manual Revision 1 - MAY 2023
69
WIRE SIZES, TYPES AND LOCATIONS
Table 6. SpeedGate Electrical Connecons References
2. Between the SpeedGate and the Operator Cabinet
2.1 Motor cables to be kept a minimum of 18 inches (46cm) from
the secondary (control) wiring.
--
2.2 Mul-Conductor Low Voltage Cable (see 1.1 above) --
2.3 Encoder Cables • “5. ENCODERS” on page
94 to page 96
3. Between the Vehicle Loops and the Operator Cabinet • “Installaon Instrucons for
Oponal Vehicle Detectors”
on page 80
• “8. VEHICLE LOOPS” on page
99
3.1 Vehicle Detector Loops Leads
4. From Operator Cabinet to Building
4.1 Power Supply (2 hots, 1 ground @ 208-240V single phase) • “Wiring Installaon” on page
57
4.2 Control Wiring
