SPEEDGATE INSTALLATION
Gate Installaon
Use extreme cauon when handling, moving, or slinging the panel secons. Black
gate edges may be installed (one horizontal on boom of outer panel secon, two
vercal on inner panel secon). They are suscepble to damage if mishandled.
Always use blocking when working with panels to prevent damage to gate edges.
1. Using slings and/or appropriate straps, secure a strap onto the liing assembly that is provided with
the gates. Once secure, begin liing unl strap is taut but not liing the gate. The gate can now be
unbolted from the shipping skid. Once all bolts are unfastened raise the gate up and place onto the
concrete anchors in the concrete foundaon.
Figure 9. Gate and Liing Assembly
