SPEEDGATE INSTALLATION
2. Place columns using leveling nuts/washers, maintaining base ange plate as close to the pile surface
as possible. Refer to diagram steps 12 to 15 above.
Columns are le/right side specic. Take note of the photo eye plate and hinge
mounng hole locaons. Photo eye locaon cut-out should face toward the gate
opening; the hinges (see Figure 10) should face toward the Secure Side (this will allow
for the gate to swing into the property when opening). If you require the gate to open
AWAY from the Secure Side, reverse the locaon of the hinge mounng holes. As per
UL 325 a SpeedGate opening toward the Public Side must have the panels remain
over the owner’s property and not move out onto a public sidewalk or street.
Figure 10. Photo Eye Plate and Hinge Mounng Locaons
