MANUAL OPERATION USING THE BRAKE DISCONNECT CABLE
Manual Operaon Using the Brake Disconnect
Cable
To manually move the SpeedGate by hand follow the instrucons below.
Before beginning the procedure ensure:
• You have the access door keys and operator keys.
• The gate is not moving.
1. Ensure that both operator DC switches are
powered OFF. If no automac gate movement
is possible then you may proceed to step 2.
2. Remove the Lower Access Doors on both
columns so that the brake disconnect cable is
visible. The cables should be free hanging.
3. In one column pull down on the cable unl you
see the indicated cable clamp, and lock the
clamp into the groove provided. It is located
on the inner edge in the center along the
top edge of the Lower Access Door Opening.
Repeat for the other column.
