OPTIONAL GATE STATUS PROXIMITY SENSORS AND MOUNTING PLATES
Oponal Gate Status Proximity Sensors and Mounng Plates
If ordered, gate status proximity sensors and mounng plates are shipped in the parts crate(s) to lessen
the chance of damage during shipping. The mounng plates are to be mounted aer the gate is installed.
Once the switches have been mounted, fasten with the provided self-tapping screws. For wiring of the
proximity switches please follow the wiring diagram provided with the sensors.
Oponal Strobe / Trac Lights
Strobe/Trac light(s) are mounted using the provided self threading fasteners. The mounng locaon is
determined by the customer, but the boom of the strobe/trac light must be mounted no lower than
7 feet (2.13m). The wiring must be pulled to the post terminaon box. Holes for wiring must be drilled
aer mounng locaon has been determined. The wiring passes through the boom of the base plate.
