Figure D–17: Exhaust solenoid connection
From instrument exhaust connection (12-mm OD)
To laboratory exhaust port (12-mm OD)
Exhaust solenoid cable
2. Connect the other end of the cable to the exhaust solenoid connection on the rear panel of
the instrument (see External wiring and vacuum connections).
D.9
Connecting the workstation
Warning: To avoid injury from electrical shock or fire, and damage to the equipment, follow
these guidelines:
• Do not expose the workstation or ancillary equipment to dripping or splashing liquids.
• Do not place objects filled with liquid, such as solvent bottles, on top of the workstation or
ancillary equipment.
June 15, 2017, 715003956 Rev. F
Page 109
