D.6.2 Disconnecting the internal source exhaust valve
When moving the QDa detector, you must disconnect the source exhaust valve tubing. Perform
the following procedure to disconnect the tubing.
Note: On Standard QDa detectors, ensure that you disconnect the 6-mm O.D. tube from the
diaphragm pump’s 6-mm elbow to the 2.5-L bottle-stopper assembly (shown in the figure "Waste
connections" in Connecting the 2.5-L waste container).
Required materials
• Chemical-resistant, powder-free gloves
To disconnect the internal source exhaust valve tubing:
Requirement: Wear clean, chemical-resistant, powder-free gloves when performing
this procedure.
1. Disconnect the source exhaust PTFE tubing from the 90-degree elbow connector on the
source exhaust valve.
2. Remove the tubing from the hose brackets alongside the QDa panel (if the tubing is in a
rear-facing configuration).
3. Disconnect the drain tubing from the waste-liquid drain port.
D.7
Source exhaust tubing
D.7.1 Connecting the exhaust-trap bottle
Perform the following procedure to install and connect an exhaust-trap bottle to the instrument
(see Exhaust trap bottle).
Required materials
• Chemical-resistant, powder-free gloves
• Utility knife
• 90-degree push-in elbow (410004340)
• 90-degree elbow (410002348)
• 12-mm PTFE tubing (6070283)
