Securing screws
Pumping block
8. Fit the ion block and source components to the instrument (see Refitting the source
components).
9. Fit the source enclosure to the instrument (see Fitting the source enclosure to the
instrument).
3.11
Emptying the nitrogen exhaust trap
Inspect the nitrogen exhaust trap in the instrument’s exhaust line daily, and empty it before it is
more than 10% full.
June 15, 2017, 715003956 Rev. F
Page 49
