Figure 2–1: Inserting the probe
PEEK fitting
Probe assembly
Probe fitting
Capillary
3. Secure the probe tubing to the side of the source enclosure using the clip.
2.4
Starting the instrument
Warning: To avoid injury from electrical shock or fire, and damage to the equipment, follow
these guidelines:
• Do not expose the workstation or ancillary equipment to dripping or splashing liquids.
• Do not place objects filled with liquid, such as solvent bottles, on top of the workstation or
ancillary equipment.
