3.8 Maintaining the source components
Clean the source components when these conditions apply:
• The sample cone and cone gas nozzle are visibly fouled.
• You have dismissed inlet and sample-related causes for decreased signal intensity.
3.8.1
Removing the sample cone assembly from the ion block
Required materials
• Chemical-resistant, powder-free gloves
Warning: To avoid personal contamination with toxic materials, wear clean, chemical-
resistant, powder-free gloves when performing this procedure.
Warning: To avoid burn injuries, allow the ion block to cool before performing this
procedure.
To remove the source components from the ion block:
1. Remove the source enclosure (see Removing the source enclosure from the instrument).
2. Remove the gas cone and PEEK cone clamp by pulling the cone clamp away from the
instrument.
June 15, 2017, 715003956 Rev. F
Page 31
