Figure 1–2: QDa with external source exhaust (KAB version)
QDa with external source exhaust (KAB version)
Note: In the figure, the assembly cover is depicted as transparent to reveal the tubing
connections.
See also: Maintenance Procedures
External Connections
1.7
ACQUITY Diverter Valve
The ACQUITY Diverter Valve is supplied as an optional accessory to the ACQUITY QDa
Detector. The diverter valve is used to divert column eluent from the QDa to waste when handling
variable samples and solutions, and can also support sample loop injections. You can attach the
diverter valve to the QDa instrument using the bracket assembly supplied with the diverter valve
kit.
See also: Optional ACQUITY diverter valve
June 15, 2017, 715003956 Rev. F
Page 19
