B Specifications
The applicability of the following specifications depends on the conditions in individual
laboratories. Refer to the ACQUITY QDa Detector System Site Preparation Guide, or contact the
Waters Technical Service organization for additional information about the specifications.
B.1 Physical specifications
The following table lists the physical specifications for the ACQUITY QDa detector.
Table B–1: Physical specifications
Attribute Standard QDa Performance QDa
Height 21.6 cm 21.6 cm
Width 37.4 cm 37.4 cm
Depth 76.1 cm 64.6 cm
Weight 34 kg 29 kg
B.2 Environmental specifications
The following table lists the environmental specifications for the ACQUITY QDa detector.
Table B–2: Environmental specifications
Attribute Specification
Operating temperature (performance is specified) 15 °C to 28 °C
Safe operating temperature (no damage or hazard) 4 °C to 40 °C
Operating humidity 20% to 80%, non-condensing
B.3 Electrical specifications
The following table lists the electrical specifications for the ACQUITY QDa detector.
