Exhaust hose brackets
PTFE exhaust tubing
Exhaust trap bottle
Source exhaust tube elbow connector
Waste liquid drain port
Figure D–9: Internal source exhaust valve—front configuration
Source exhaust tube elbow connector
Waste liquid drain port
PTFE source exhaust tube and elbow connector (ensure a downward gradient)
Exhaust trap bottle
