Required materials
• Chemical-resistant, powder-free gloves
• 7-mm nut driver
• 8-mm hex wrench
• Utility knife
• NW16 clamp (included in the installation kit)
• NW16 O-ring (included in the installation kit)
• PVC exhaust tubing (included in the installation kit)
• PVC hose clamps (included in the installation kit)
• 1-inch ID vacuum hose (included in the installation kit)
Warning: To avoid personal contamination with biohazardous or toxic compounds, wear clean,
chemical-resistant, powder-free gloves when performing this procedure.
Notice: To ensure the correct operation of the backing pump, it must be installed
within one degree of horizontal.
Notice: The area where the backing pump is located must have an ambient
temperature of 15 to 40 ºC (59 to 104 ºF).
Note: To ensure proper ventilation, the pump must be installed with the following minimum
clearances:
