Source exhaust connection
Holding screw
Convoluted liquid waste tubing
Blanking fitting
Unused source exhaust connection
Note: In the figure, the assembly cover is depicted as transparent to reveal the tubing
connections.
Figure D–7: External source exhaust valve assembly—front configuration
Blanking fitting
API gas connection
Unused source exhaust connection
Holding screw
Convoluted liquid waste tubing
Exhaust tubing
Source exhaust connection
