PTM30112-G
12/07/2012
W
E
CRUSH
HAZARD
CUTTING
HAZ ARD
CRUSH
HAZARD
CRUSH
HAZARD
FALLING
HAZ ARD
CRUSH
HAZARD
PINCH
HAZ ARD
PUNCTURE
HAZ ARD
FRAMELESS CAR
ASSEMBLY
SERIES : 015 - 016 - 018 - 115 - 116 - 118
C
A
B
B
A
SLING
WALL
FLOOR
CLEARANCE
Step
Walls on all cars except the Designer hang past the car oor. Before fastening oor to sling be sure to
allow enough clearance between car oor and sling upright.
Step
Drill (4) holes minimum (If sling extensions are provided, drill 6 - 8 holes depending on extension con-
guration) and bolt oor to sling using provided hardware (Verify clearance between car oor and all
hoistway walls. Refer to eld drawings for details).
Step
Insert wall B [or rail wall] with fasteners onto oor A pins and slide into place.
Note: Do not allow the wall to tilt forward or backward as this may cause damage.
Step
Carefully place the gate pocket C with dowels into oor at the same time connecting the fasteners
between B & C.
4
5
6
7
4
5
6
7
Support walls during assembly. Tilting forwards or backwards on dowels could result in damage to the
walls and/or fasteners and prevent proper assembly of car. Do not allow walls to slide o the oor this
may cause harm to yourself and the walls.
