WBOX Technologies 0E-13D28 User Manual

High-Resolution IR Camera
User Manual
Web Operation
Issue V1.0 (2018-05-11)
33
4.4.5 Configuring Device Ports
Description
You must configure the HTTP port, control port, Real Time Streaming Protocol (RTSP)
port and RTMP port for device route mapping in a LAN.
Procedure
Step 1 Choose Configuration > Device > Device Port.
The Device Port page is displayed, as shown in Figure 4-12.
Figure 4-12 Device Port page
Step 2 Set the parameters according to Table 4-7.
Table 4-7 Device port parameters
Parameter
Description
Setting
Control Port
Port used for audio and video transfer
and signaling interaction.
[Setting method]
Enter a value manually.
[Default value]
30001
HTTP Port
Port used in web access.
[Setting method]
Enter a value manually.
[Default value]
80
RTSP Port
RTSP protocol port.
[Setting method]
Enter a value manually.
[Default value]
554
